This communication equipment is perfect for tracking and managing fleets or location services of private vehicles. It combines the precision of GPS with the power of technology for 3G Wireless network.

GENERAL
SUPPORTED NETWORKS GPRS over GSM.
COMA lx EV DO. INPUTS/OUTPUTS
8 General Programmable Input/Outputs (GPIOs). Output type: Open collector.
Output Capacity: Up to 40V @ 100mA. Input-Sink: max lmA. ENVIROMENTAL <
Operating Temperature: 5°C to 500C (41°F to 122°F). Storage Temperature: -40oC to 660C.
Relative humidity: 5% to 95% without condensation. PHYSICAL DIM ENSIONS
(H x W x D) = x x mm.
WEIGHT: 0 g.
HOUSING: luminous.
INDICATORS
4 LED, solid or blinking signals, Power, On-Line, Signal, Fix.
GPRS SPECIFICATIONS
- Frequencys: 850, 900, 1800, 19OO MHz.
- Full duplex communication.
- Receiver sensivity at antenna connector: < -102dBm
- Transmitter Output power: Class 4, 2W (33dBm).
- Antenna Impedance: 50 Ohms.
- GPRS Speeds: Up to 114000 bps.
- Automatic start up.
- Antenna Connector: SMA type.
- Modulation: GMSK (Gaussian Minimum Shift Keying)
- SIM Card: 3/5 Volts.
- SIM Card PIN: Programmed by user one time, automatically introduced
Onward.
GPS SPECIFICATIONS
- Frequency: L1 type.
- Channels: 12, continuous tracking receiver.
- Correlators: 32 GPS correlators.
- Protocols: TSIP (Binary), NMEA 0183 (ASCII), TAIP(ASCII), DGPS.
- Update rate: TSIP @ 1Hz, NMEA @ 1Hz, TAIP @ 1Hz.
- Accuracy: 25m CEP (50%) wlo SA
- Accuracy Velocity: O.lm/sec
- Antenna connector: SMA
- Adquisition: Cold Start < 130 (90%), Warm Start < 45 seconds (90%), Hot
- Start < 20 seconds (90%).

PERSONAL GPS SPECIFICATIONS
• 850/900/1800/1900 frequency bands
• Voice
• SMS
• Circuit-switched data
• GPRS
• GPS/A-GPS with tracking of up to 14 satellites
• Optional multi-day ephemeris support
• Time to first fix: 2 s @ 5 m; 2 sec navigation fixes (with assistance data)
• Motion sensor and vibrating alerts
• Optimized data pipe
• Network router
• Control and automation
• Rules engine
• Application OS
• Battery ( 2 DAY )

Easy to configure. Stores, visualizes and reports the movement of mobile phones, from a unit to a full fleet.Access to operation groups, subgroups, and combinations of vehicles even different companies. Simultaneous control in different localities, cities and countries.Reads and stores different data chains or traces of GPS equipment available in the market. Availability of permanent historical information. Sure, fast and easy handling.

Eagle View 1 (Personal)
It allows tracking personnel with the following characteristics:
-- Exact location of the vehicle in a photograph of google earths accompanied by a map and another mapping option of viewing google earths fully referenced nationally.
-- Freezing of the vehicle remotely in a matter of seconds.
-- Intercept and recovery of the vehicle inside and outside the country with our own private force.
-- Access to the website where you can locate the vehicle in real time and generate reports.
-- Panic Button.
-- Access to know the location of their vehicle through cellular.


Eagle View 2 (fleet)
It allows tracking of an entire fleet with the following characteristics:
-- Exact location of all vehicles in the fleet to the same cartographic map and a single photograph of google earths with benchmarks at the national level.
-- Freezing of vehicles remotely within seconds.
-- Intercept and recovery of any vehicle in the fleet inside and outside the country with our own private force.
-- Access to our website where you can locate and create all kinds of reports and historical sites that can be generated in (Word, Exell and PDF)
-- Access to location of any vehicle fleet through cellular.
-- Panic Button.


Eagle View 3 (Lock satellite)
It allows tracking of any container without opening the container and take it to damage the marks of quality, has the following characteristics:
-- Lock the satellite account with the exact location of this container is seen on a map and a photograph of cartographic google earths.
-- Shows speed and route that leads or whether its stationary.
-- Has predetermined route in the case that this deviates.
-- Access to Web where you can locate and generate any kind of report that specifies the route of that container.
-- It has an independent load and a censor in case of unwanted opening of the container.
-- It's made of a material that does not allow its handling and has a Multilock.

Eagle View PRO

This is an application of GPS developed to show the vehicle location on a map mapping report with updated at all times of the exact location of the vehicle as well as the ability to generate historical.

Eagle View Mobile

This application of GPS has been developed to facilitate the user to access the GPS system where you can give exact location of the vehicle through different mobile teams (cellular, pocket and PDAs).

Eagle View Online

This application of GPS has been developed so the user can have its own monitoring of vehicles at any time from anywhere in the world with only having access to the Internet, the client readily enters to our website where you can access the following applications: exact location of the vehicle with reports updated every minute on different platforms of location, can also generate different types of historical either on an hourly or daily access to different types of statistics for control of different types of fleets and with the ability to bring to export them (PDF, Word, Excel, HTML and FlashPaper).

• Personal computer with Network Card

• Internet Explorer 6.0 0 Higher

• Internet Connection

• Have at least one unit InterDev

• Timely payment to access the system WEB

• Access Cell chip with GPRS and SMS capacity

• Java platform

• Goggle Earth Free Edition

• Flash Player Active X
